Product description:

Standard flame retardant composite cable structure is the structure of the single mode or multimode fiber into a loose tube made of high modulus plastic, the casing filled with water blocking compounds. The core center is a phosphating wire or to get on a polyethylene rope, loose tube (or filling rope and signal line) are stranded around the strength member into a compact and circular cable core, the cable core is filled steel filler - polythene bonded sheath with water resistance, blue flame retardant PVC sheath cable.

Product features:

Precise control of the length of the fiber ensures that the optical cable has a good tensile and temperature characteristics

- cannola material itself has hydrolysis resistance and high strength good, special tube filling compound ensure critical protection of fiber

Good resistance and flexibility.

Adopt the following measures to ensure the waterproof performance of the optical cable

A single wire center reinforcement

Loose tube filled with special fiber paste

100% cable core filling

Good water resistance material to prevent the longitudinal seepage of optical cable

Tight binding between two layers of sheath and the two

Technical parameter:

Number of optical cable core diameter of optical cable weight allowed tensile allowable press force

(mm) (kg/km) long / short term (N) long / short term (N/10cm)

2-24 10.9 161 600/1500 300/1000

2-24 10.9161 300/1000 600/1500

26-48 12.5 196 600/1500 300/1000

26-48 12.5196 300/1000 600/1500
